SETUP & CHARGING
Connect with
confidence.
The same installation steps work for E100 and E100 Prime. Choose a topic below to get started.
Jump to a section
Attach first. Power on last.
- Keep the battery switched off.
Align it with Mini and check that it is securely fitted.
- Open the built-in stand.
Use a stable, level surface and give Mini a clear view of the sky.
- Switch on after assembly.
Connect a charger only after checking the source, connector and model requirements.
Installation guideFor E100 and E100 Prime
E100 shown. The same attachment steps apply to E100 Prime. Select the image to enlarge it in a new tab. Starlink Mini is not included.
ORIGINAL PRODUCT VIDEO
See how the battery fits.
Watch the original hands-on assembly demonstration.
E100 shown. Mounting demonstration; charging ports differ by model. Starlink Mini is not included.
E100
Use a compatible DC source.
- DC battery charging
- 25.2–30 V
- USB-C
- No USB-C port
- DC while Mini runs
- 26.5–30 V
Start with the included power charger or the original Mini power charger. Both support charging while Mini is in use. E100 has no USB-C port.
E100 PRIME
DC or USB-C PD.
- DC battery charging
- 12–30 V
- USB-C
- Up to 60 W input/output · PD 3.0
- DC while Mini runs
- 12–30 V
Recharge with the included power charger or a compatible USB-C PD source. Prime also supports charging while powering Mini; charging speed depends on the source and load.
Keep ports dry before connecting.
Close unused covers fully. After rain or splashes, wipe the battery and let the port area dry fully before attaching a charger or cable. Do not submerge the battery. Use the power charger indoors and keep it dry. Outdoor battery use does not make the charger weather resistant.
Charging questions Contact support
